Scaling a nd Positioning a Waveform
Use the horizontal controls to adjust the time base, adjust the trigger point, and to examine waveform details more closely.
You can also use the Wave Inspector Pan and Zoom controls to adjust the display o f waveforms. (See page 118, Using
Wave Inspector to Manage Long Record Length Waveforms.)
Original waveform Scaled horizontally Positioned horizontally
Use the vertical controls to select waveforms, adjust the waveform vertical position and scale, and set input parameters.
Push a channel menu button (1, 2, 3,or4) as many times as needed and the associated menu items to select, add, or
remove a waveform.
Original wa veform Scaled vertically Positioned vertically
MSO3000 and DPO 3000 Series Oscilloscopes User Manual 89
