Save and Recall I
nformation
Saving and Recalling Setups
Setup information includes acquisition information, such as vertical, horizontal, tri gger, cursor, and measurement information.
It does not include communications information, such as GPIB addresses. To save the setup information:
1. Push Save / Recall Menu .
2. Push Save Setup or Recall Setup on the
lower menu.
Save
Screen
Save
Waveform
Save
Setup
Recall
Waveform
Recall
Setup
Assign
Save|to
Setup
File
Utilities
Save
Setup
To File
Edit Labels
3. From the resulting side menu, select the
location to save the setup to or to recall it
from.
To save setup information to one of the ten
internal setup memories in the oscilloscope,
push the appropriate side menu button.
To save setup information to a USB file,
push To File.
To Setup 1
To Setup 2
–more–
4. IfyouaresavinginformationtoaUSBflash
drive, turn multipurpose knob a to scroll
through the file structure. (See page 124,
External file structure.)
Push S elect to open or close file folders.
MSO3000 and DPO 3000 Series Oscilloscopes User Manual 129
