Printing a Hard Copy
To print an image of what appears on the oscillo scope screen, do the following procedure.
Connect a Printer to Your Oscilloscope
Connect a non-PictBridge printer to a USB port on the rear or front-panel of the oscilloscope. Alternatively, connect a
PictBridge
printer to the USB device port on the rear panel or hook up a networked printer through the Ethernet port.
Set Up Print Parameters
To set up the oscilloscope to print hard copies:
1. Push Utility.
2. Push Utility Page.
Utility
Page
3. Turn multipurpose knob a and select Print
Setup.
Print Setup
4. Push Select Printer if you are changing the
default printer.
Utility
Page
Print Setup
Select
Printer
???
Orientation
Landscape
Ink Saver
On
Turn multipurpose knob a to scroll through
the list of available printers.
Push Select to choose the desired printer.
To add a non-PictBridge USB printer to the
list, plug the printer into a USB host port.
The oscilloscope will automatically recognize
most printers.
To set up a PictBridge USB printer, refer to
the next topic.
To add an Ethernet printer to the list, refer
to that topic. (See page 135, Printing Over
Ethernet.)
