Tektronix MSO3000 Series - Positioning, Scaling, and Grouping Digital Channels

Display Wavefor
mData
Labeling bus signals. To label a bus, do the following steps:
1. Push the appro
priate front-panel bus button.
2. Push Label.
(See page 45, Labeling Channels and Buses.)
Bus (B1)
I2C
Define
Inputs
Thresholds Include
R/W in
address
No
(B1) Label
I2C
Bus
Display
Event
Table
Positioning, Scaling, and Grouping Digital Channels
1. Push D15–D0 on the front-panel.
2. Push D15–D0 on the lower menu.
D15 – D0
On/Off
Thresholds Edit Labels MagniVu
On |
Off
Height
S |ML
3. Push Select on the s ide menu.
Select
(a) D0
(b) 1.08 div
Display
On|Off
Turn on
D7–D0
Turn on
D15–D8
MSO3000 and DPO 3000 Series Oscilloscopes User Manual 95
