Installation
8. You should now see the e*Scope screen
showing the oscilloscope display, on your
Web browser.
If e*Scope does not work, rerun the
procedure. If it still does not work, contact
qualified ser
vice personnel.
Connecting
a USB Keyboard to Your Oscilloscope
You can connect a US-style USB keyboard to a US B Host port on the rear or front-panel of the oscilloscope. The oscilloscope
will detect the keyboard, even if it is plugged in while the oscilloscope is powered on.
You can use the keyboard to quickly create names or labels. You can bring up the Label menu using the lower label button of
the Channel or Bus menus. Use the arrow keys on the keyboard to move the insertion point, and then type in a name or
label. Labeling channels and buses makes the information on the screen easier to identify.
28 MSO3000 and DP O3000 Series Oscilloscopes User Manual
