Tektronix MSO3000 Series - Setting up Digital Channels

Acquire the Sign
al
Setting Up Digital Channels
Use front-panel buttons and knobs to set up your instrument to acquire signals using the digital channels.
1. Connect the P6316 16-channel digital probe
to the input signal source.
2. Connect the ground lead or leads to the
circui
t ground.
You can connect one or two of the common
ground leads for each group of 8 channels
(wires
).
3. If needed, connect the appropriate grabber
for ea
ch probe to the probe tip.
4. Connect each channel to the desired circuit
test
point.
5. Push D15 - D0 on the front-panel to display
the m
enu.
6. Pus
h D15 - D0 on the lower menu to access
the D15 - D0 On or Off menu.
D15
–D0
On/Off
Thr
esholds
Edi
t Labels
Mag
niVu
On |
Off
Hei
ght
S |ML
66 MSO3000 and DP O3000 Series Oscilloscopes User Manual
