Using A pplication Modules
Optional application module packages extend the capability of your oscilloscope. (See page 12, Application Module Free
Trial.) You c an install up to four application modules at one time. (See page 13, Installing an Application Module.)
Refer to the MSO3000 and DPO3000 Series Oscilloscopes A pplication Module Installation Manual that came with your
application module for instructions on installing and testing an application module. Some modules are described in
the following list. Additional modules may be available. Contact your Tektronix representative or visit our Web site at
www.tektronix.com for more information. Also, refer to Contacting Tektronix at the beginning of the manual.
The DPO4AERO Aerospace Serial Triggering and Analysis Module adds triggering on MIL-STD-1553 buses, as well
as analytical tools to help you efficiently analyze your serial bus. These include digital views of the signal, bus views,
packet decoding, search tools, and event tables with timestamp information.
The DPO3 AU D IO Audio Serial Triggering and Analysis Module adds triggering on I
2
S, Left Justified (LJ), Right
Justified (RJ), and TDM buses, as well as analytical tools to help you efficiently analyze your serial bus. These include
digital views of the signal, bus views, packet decoding, search tools, and event tables with timestamp information.
The DPO3AUTO Automotive Serial Triggering and Analysis Module adds triggering on packet level information
in serial buses used in automotive designs (CAN and LIN), as w ell as analytical tools to help you efficiently analyze
your serial bus. These include digital views of the signal, bus views, packet decoding, s earch tools, and event tables
with timestamp information.
The DPO3COM P Computer S erial Trigg e ring and Analysis Module adds triggering on byte or packet level information
in RS-232, RS -422, RS-485, and UART buses, and analytical tools to help y ou efficiently analyze your serial bus. These
include digital views of the signal, bus views, packet decoding, search tools, and event tables with timestamp information.
The DPO3EMBD Embedded S erial Triggering and Analysis Module adds triggering on packet level information in
serial buses used in embedded designs (I
2
C and SPI), as well as analytical tools to help you efficiently analyze your
serial bus. These include digital views of the signal, bus views, packet decoding, search tools, and event tables with
timestamp information.
The DPO4FLEX Serial Triggering and Analysis Module offers FlexRay serial bus support, as well as analytical tools
to help you efficiently analyze your serial bus. These include digital views of the signal, bus views, packet decoding,
search tools, and event tables with timestamp information.
The DPO3PWR Power Analysis Module adds measurements of power quality, switching loss, harmonics, ripple,
modulation, safe operating area, and slew rate.
The DPO3VID Extended Video Module adds triggering on a variety of standard HDTV signals, as well as on custom
(non-standard) bilevel and trilevel video signals with 3 to 4,000 lines.
