Analyze Wavefor
mData
Search Description
Rise/Fall Tim
e
Search for ris
ing and/or falling edges that are >, <, =, or ≠ a user specified time.
Bus
Parallel: Sea
rch for a binary or hex value (MSO3000 Series only).
I
2
C: Search for Start, Repeated S tart, Stop, Missing Ack, Address, Data, or Address and
Data.
SPI: Search f
or SS Active, MOSI, MISO, or MOSI & MISO
RS-232, RS-422, RS-485, UART: Search for Tx S tart Bit, Rx Start Bit, Tx End of Packet, Rx
End of Packet, Tx Data, Rx Data, Tx Parity Error, Rx Parity Error.
CAN: Search
for Start of Frame, Type of Frame (Data, Remote, Error, Overload), Identifier
(standard or extended), Data, Identifier and Data, End of Frame, or Missing Ack, Bit Stuffing
Error
LIN: Searc
h for Synch, Identifier, D ata, ID & Data, Wakeup Frame, Sleep Frame, Error
FlexRay: Search for Start of Frame, Type of Frame, Identifier, Cycle Count, Header Fields,
Data, ID & Data, End of Frame, Error
I
2
S, LF, RJ
: Search for Word Select or Data.
TDM: Search for Frame Sync or Data.
MIL-STD-1553: Search for Sync, Command, Status, Data, Time (RT/IMG), Error
Analyzing Power
Acquire, measure, and analyze power signals with the DPO3PWR Power Analysis M odule. To use this application:
1. Push Test.
2. Push A
nalysis.
Appli
cation
Analy
sis
None
3. Use t
he side menu to select the desired
analysis function.
Choose among power quality, switching
los
s, harmonics, ripple, modulation, and
safe operating area, and deskew.
