Preface
Key Features
MSO3000 and DPO3000 Series instruments can help you verify, debug, and characterize electronic designs. Key features
include:
500 MHz, 300 MHz, and 100 MHz bandwidths – models with 100 MHz or 300 MHz bandwidths can be upgraded up
to 500 MHz
2 channel and 4 channel models
Sample rates up to 2.5 GS/s on all analog channels
5 M points record length on all channels
50,000 waveforms/second display rate
Bus triggering and analysis (with the appropriate application module and model oscilloscope) for I
2
C, SPI, M IL-STD-1553,
CAN, LIN, FlexRay, RS-232, RS-422, RS-485, UART, I
2
S, Left Justified (LJ), Right Justified (RJ), TDM
Power analysis application module (optional)
Wave Inspector controls for managing long record lengths, with zoom and pan, play and pause, search and mark
229 mm (9 inch), with 800 x 480 resolution, WVGA color display
Small and lightweight, at 127 mm (5 inches) deep and 4.1 kg (9 pounds)
USB available for quick and easy storage
Direct printing to any PictBridge-compatible printer
Built-in Ethernet port
USB 2.0 device port for direct P C control of the oscilloscope using USBTMC protocol
OpenChoice documentation and analysis software
NI LabVIEW SignalExpress™ Tektronix Edition productivity and analysis software
Remote viewing and control with e*Scope
Remote control with VISA connectivity
TekVPI Versatile Probe Interface supports active, differential, and current probes for automatic scaling and units
MSO3000 Series Mixed Signal Oscilloscopes also offer:
MagniVu 121.2 ps resolution
Parallel bus triggering and analysis
16 digital channels
Easy connection to your device-under-test through the convenient design of the P6316 digital probe
MSO3000 and DPO3000 Series Oscilloscopes User Manual xiii
