Trigger Setup
Choosing a Trigger Type
To select a trigger:
1. Push Trigger Menu.
Trigger
Type
Sequence
(B Trigger)
Pulse
Width
Timeout
Runt
Logic
Setup &
Hold
Rise/Fall
Time
Video
2. Push Type to
bringuptheTrigger Type
side menu.
NOTE. The bus trigger in the M SO3000 Series
works on pa
rallel buses even without an
application module. Using the bus trigger on
other buses requires use of the DPO3A ERO ,
DPO3AUDIO
, DPO3AUTO, DPO3EMBD,
DPO3COMP, or DPO3FLEX application
module.
Bus
3. Turn mu
ltipurpose knob a to select the
desired trigger type.
4. Compl
ete the trigger setup using the lower
menu controls displayed for the trigger
type. The controls to set up the trigger vary
depe
nding on the trigger type.
Type
Edge
Source
1
Coupling
DC
Slope
Level
100 m
V
Mode
Auto
& Holdoff
MSO3000 and DPO 3000 Series Oscilloscopes User Manual 73
