Analyze Wavefor
mData
Customizing an Automatic Measurement
You can customize automatic measurements by using gating, modifying measurement statistics, adjusting the measurement
reference levels, or taking a snapshot.
Gating
Gating confi
nes the measurement to a certain portion of a waveform. To use:
1. Push Measur
e.
2. Push More as many times as needed to
select Gating from the resulting pop-up
menu.
Add Mea-
surement
Remove
Measure-
ment
Indicators
More
Bring
Cursors
On Screen
3. Position the gates using the side menu
option
s.
Gating
Off
(Full
Record)
Screen
Between
Cursors
104 MSO3000 and DP O3000 Series Oscilloscopes User Manual
