Analyze Wavefor
mData
Statistics
Statistics characterize the stability of measurements. To adjust statistics:
1. Push Measure.
2. Push More as many times as needed to
select Statistics from the resulting pop-up
menu.
Add Mea-
surement
Remove
Measure-
ment
Indicators
More
Bring
Cursors
On Screen
Statistics
On|Off
Mean &
Std Dev
Samples
(a) |
32
3. Push the side menu options. These include
whether to turn statistics on or off and how
many samples to use for mean and standard
deviation calculations.
Reset
Statistics
Snapshot
To see all the single-sourced measurements at one moment in time:
1. Push Measure.
2. Push Add Measurement on the lower
menu
.
Add Mea-
sure
ment
Remove
Meas
ure-
ment
Indicators
More
Bring
Curs
ors
On Screen
MSO3000 and DPO 3000 Series Oscilloscopes User Manual 105
