Acquire the Sign
al
Hi Res mode calculates the average of all
the samples for each acquisition interval.
This mode only
works w ith real-time,
noninterpolated sampling. Hi-Res provides
a higher-resolution, lower bandwidth
waveform.
Envelope mo
de finds the highest and lowest
record points over all acquisitions. Envelope
uses P eak Detect for each individual
acquisitio
n.
Average mode calculates the average value
for each re
cord point over a user-specified
number of acquisitions. Average uses
Sample mode for each individual acquisition.
Use avera
ge mode to reduce random noise.
Changing the A cquisition Mode, Record Length, and Delay Time
Use this procedure to change the acquisition mode.
1. Push Acquire.
2. Push Mode.
Mode
Samp
le
Record
Length
10k
Delay
On |
O
ff
Set Horiz.
Position to
10%
Waveform
Display
XY Display
Off
MSO3000 and DPO 3000 Series Oscilloscopes User Manual 51
