After having properly set up the acquisition, triggering, and display of your desired waveform, you can then analyze the
results. Select from features such as cursors, automatic measurements, statistics, math, and FFT.
Taking Automatic Measurements
To take an automatic measurement:
1. Push Measure.
2. Push Add Me
asurement.
Add Mea-
surement
Remove
Measure-
ment
Indicator
s
More
Bring
Cursors on
Screen
Configure
Cursors
3. Turn multipurpose knob a to select the
specific measurement. If needed, then turn
multipu
rpose k nob b to select the channel to
measure on.
4. To remove a measurement, push Remove
Measurement, turn multipurpose knob a to
selec
t the specifi c measurement, and push
OK Remove Measurement on the side
menu.
Quick Tips
To remove all m easurements, select Remove All Measurements.
A symbol appears instead of the expected numerical measurement if a vertical clipping condition exists. Part o f the
waveform is above or below the display. To obtain a proper numerical measurement, turn the vertical scale and position
knobs to make all of the waveform appear in the display.
