Display Wavefor
mData
Display Wavef
orm Data
This section contains concepts and procedures for displaying the acquired waveform.
Adding and Removing a Waveform
1. To add or remove a waveform from
the display, push the corresponding
front-panel channel button or the D15-D0
button.
You can use the channel as a trigger
source whether or not it is displayed.
Setting the Display Style and Persistence
1. To set the display style, push Acquire.
2. Push Waveform Display.
Mode
Sample
Record
Length
10k
Delay
On |
Off
Set Hor
iz.
Position to
10%
Wavefo
rm
Display
XY Display
On
84 MSO3000 and DP O3000 Series Oscilloscopes User Manual
