Installation
3. Push Utility P
age.
Utility
Page
4. Turn multipurpose knob a and select I/O.
I/O
5. Push Ether
net Network Settings.
Utility
Page
I/O
USB
Computer
Ethernet
Network
Settings
Socket
Server
GPIB
1
6. On the side menu, if you are on a DHCP
Ethernet network and using dynamic
address
ing, set DHCP to On. If you are
using static addressing, set it to Off.
Change
Instrume
nt
Settings
Push Ch
ange Instrument Settings.Ifyou
are using DHCP, note the Ethernet address
and instrument name. If you are using S tatic
addre
ssing, enter the Ethernet address you
will be using.
DHCP/
BOOTP
On|Of
f
Test Con-
nection
NOTE. Depending on the type and speed
of network to which your DPO3000 Series
osci
lloscope is connected, you may not see the
DHCP/BOOTP field update instantaneously
after pressing the DHCP/BOOTP button. It may
tak
e a few seconds to update.
7. Start your browser on your remote computer.
In the browser address line, enter the IP
ad
dress or, if DHCP is set to On in the
oscilloscope, simply enter the instrument
name.
MSO3000 and DPO 3000 Series Oscilloscopes User Manual 27
