Application Exa
mples
To select the Rise Time measurement:
1. Push Measure.
2. Push Add Meas
urement.
Add Mea-
surement
Remove
Measure-
ment
Indicators
More
Bring
Cursors
On Screen
3. If needed, on the side menu, push Source
and turn mu
ltipurpose knob a to select the
channel from which you want to measure.
Turn multipurpose knob b to select the
Rise Time
measurement. P ush OK Add
Measurement on the side menu.
4. Push More repeatedly until you select
Reference Levels from the pop-up menu.
MSO3000 and DPO 3000 Series Oscilloscopes User Manual 145
