Trigger Setup
LIN Bus Trigger
If you are using the LIN bus trigger, you can trigger on Sync, Identifier, Data, Id & Data,Wakeup Frame, Sleep Frame,or
Error.
If you are setting up an LIN trigger and have made a Trigger On selection of Identifier, Data,orIdentifier & D ata, push
Identifier or Data on the lower menu and enter the parameters of interest on the resulting side m enu.
If you have made a Trigger On selection of Error, push Error Type on the lower menu and enter the parameters of
interest on the resulting side menu.
FlexRay Bus Trigg er
You can trigger on Start of Frame, Type of Frame, Identifier, C ycle Count, Header Fields, Data, Id & Data, End
of Frame or
Error.
Audio Bus Trigger
If you are using the I
2
S, LJ, and RJ bus, you can trigger on Word Se lect,orData.
If you are using the TDM bus, you can trigger on Frame Sync,orData.
MSO3000 and DPO 3000 Series Oscilloscopes User Manual 79
