1Ć13
*,+$$!& $&$%&% - " $$!
%$#&"!
Sensitivity 0.75 divisions of composite sync will achieve a stable display.
60 Hz Rejection Stable video trigger with up to 4 divisions of 60 Hz on the video
signal.
Sync Offset Stable video trigger if sync tip is ±15 divisions, referenced to input
ground.
)! #$&"! Stable trigger on positive or negative composite horizontal sync
(lines) video, for all 525/60 and 625/50 video systems which include:
NTSC, PAL, and SECAM.
!&$( Stable trigger on vertical sync interval >20 ms.
*,+$$!& $&$%&% - '$%"$%
%$#&"!
D '$%"$ &" ! '$) Same as Time Base Accuracy + 0.1 division.
D '$) Readouts calculated using DTime cursor difference.
Absolute Volts Accuracy Accuracies are as follows:
Condition Accuracy
-10_ C to +30_ C ±(1% of reading + 2% of one vertical
division + HF display errors + 0.5 mV +
trace shift errors).
+30_ C to +55_ C ±(1% of reading + 2% of one vertical
division + HF display errors+4mV+
trace shift errors).
D"&% '$%"$ &" ! '$) ±(1.6% of reading + 2% of one vertical division + HF display
errors).
*,+$$!& $&$%&% - #$&"!
%$#&"!
'$) ±4%.
X Bandwidth DC to at least 3 MHz.
Phase Difference Between X and Y
Amplifiers
±3_, DC to 150 kHz.
