Tektronix TDS2024 User Manual

TDS2CMA Communications Module
TDS1000/2000-Series Digital Oscilloscope User Manual
137
Testing the RS-232 Interface
To test the oscilloscope RS-232 interface, follow these steps:
1. Connect the oscilloscope to a personal computer (PC) using an
appropriate RS-232 cable (refer to the t able on page 134).
2. Power on the PC.
3. On the PC, run a terminal-emulator program such as Microsoft
Windows Hyperterminal. Make sure the PC serial port is set as
follows:
Function Setting
Baud rate
9600
Data flow control hardflagging
Parity None
4. Power on the oscilloscope.
5. Connect the oscilloscope probe to the channel 1 input c onnector.
Attach the probe tip and ground lead to the PROBE COMP
connectors.
The PROBE COMP signal is a square wave with a frequenc y
of ≈1 kHz and a peak voltage of ≈5 V. The next figure shows how
to connect the probe to the oscilloscope.

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
