Tektronix TDS2024 User Manual

TDS2CMA Communications Module
TDS1000/2000-Series Digital Oscilloscope User Manual
139
NOTE. For brief information on command entry, refer to page 150.
For complete command information, refer to the programmer manual
that came with your extension module.
10. Send the command AUTOSet EXECute to have the oscilloscope
automatically ac quire the input signal.
11. Send the command MEASUrement:IMMed:SOURCE CH1 to
select measurements on channel 1.
12. Send the command MEASUrement:IMMed:TYPe PK2 to set up
the voltage measurement.
13. Send the query MEASUrement:IMMed:VALue? to request the
measurement result. The oscilloscope will respond with a result
similar to 5.16E0, which is the voltage measurement of the
PROBE COMP signal using the standard 10X probe.
This completes the RS-232 interface test.
RS-232 Troubleshooting
If the oscilloscope and the external device (computer or printer) have
trouble communicat ing, follow these steps:
1. Verify that the module is working. Refer to Checking Module
Installation on page 130.

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
