Tektronix TDS2024 User Manual

Appendix A: Specificati ons
TDS1000/2000-Series Digital Oscilloscope User Manual
163
Oscilloscope EMC Certifications and Compliances
European
Union
Meets the intent of Directive 89/336/EEC for Electromagnetic Compatibility.
Compliance was demonstrated to the following specifications as listed in the
Official Journal of the European Communities:
EN 61326, EMC requirements for Class A electrical equipment for measure-
ment, control, and laboratory use
1,2
IEC 61000--4--2, Electrostatic discharge immunity (Performance criterion B)
IEC 61000--4--3, RF electromagnetic field immunity (Performance criterion A)
3
IEC 61000--4--4, Electrical fast transient/burst immunity (Performance criterion B)
IEC 61000--4--5, Power line surge immunity (Performance criterion B)
IEC 61000--4--6, Conducted RF immunity (Performance criterion A)
4
IEC 61000--4--11, Voltage dips and interruptions immunity (Performance
criterion B)
EN 61000--3--2, AC power line harmonic emissions
1
Emissions that exceed the levels required by this standard may occur when
this equipment is connected to a test object.
2
To ensure compliance to the standards listed above, attach only high
quality shielded cables to this instrument. High quality shielded cables
typically are braid and foil types that have low impedance connections to
shielded connectors at both ends.
3
The increase in trace noise while subjected to a test field (3 V/m over the
frequency range 80 MHz to 1 GHz, with 80% amplitude modulation at 1 kHz)
is not to exceed 2 major divisions peak--to--peak. Ambient conducted fields
may induce triggering when the trigger threshold is offset less than 1 major
division from ground reference.
4
The increase in trace noise while subjected to a test field (3 V/m over the
frequency range 150 kHz to 80 MHz, with 80% amplitude modulation at
1 kHz) is not to exceed 1 major division peak--to--peak. Ambient conducted
fields may induce triggering when the trigger threshold is offset less than
0.5 major divisions from ground reference.

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
