Appendix A: Specificati ons
164
TDS1000/2000-Series Digital Oscilloscope User Manual
Oscilloscope EMC Certifications and Compliances (Cont.)
Australia/New
Zealand
Meets the intent of Australian EMC Framework as demonstrated to the
following specification: AS/NZS 2064.1/2
U.S.A. Emissions comply with FCC Code of Federal Regulations 47,
Part 15, Subpart B, Class A Limits
Oscilloscope Safety Certifications and Compliances
Certifications
CAN/CSA C22.2 No. 1010.1-92
UL3111-1, First Edition
CSA Certified
Power Cords
CSA Certification includes the products and power cords appropriate
for use in the North America power network. All other power cords
supplied are approved for the country of use.
Pollution Degree 2 Do not operate in environments where conductive pollutants may be
present.
Overvoltage
Category
Category: Examples of Products in this Category:
CAT III Distribution-level mains, fixed installation
CAT II Local-level mains, appliances, portable equipment
CAT I Signal levels in special equipment or parts of equipment,
telecommunications, electronics
Adjustment (Factory Calibration) Interval
The recommended calibration interval is one year
Oscilloscope General Certifications and Compliances
Russian Federation
This product was certified by the G OST ministry of Russia to be
in compliance with all applicable EMC regulations.
Peoples Republic of
China
This product has received the Chinese Metrology Certification (CMC)

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
