Tektronix TDS2024 User Manual

Appendix A: Specificati ons
TDS1000/2000-Series Digital Oscilloscope User Manual
165
P2200 Probe Specifications
Electrical
characteristics
10X position 1X position
Bandwidth DC to 200 MHz DC to 6 MHz
Attenuation ratio 10:1 ± 2% 1:1 ± 2%
Compensation
Range
18 pf-35 pf Compensation is fixed; correct for
all oscilloscopes with 1 M Ω input
Input Resistance
10 M Ω ± 3% at DC 1MΩ ± 3% at DC
Input Capacitance 14.5 pf-17.5 pf 80 pf-110 pf
Rise time, typical <2.2ns < 50.0 ns
Maximum input
voltage
1
10X position 300 V
RMS
CAT I or 300 V DC CAT I
300 V
RMS
CAT II or 300 V DC CAT II
100 V
RMS
CAT III or 100 V DC CAT III
420 V peak, <50% DF, <1 s PW
670 V peak, <20% DF, <1 s PW
1X position 150 V
RMS
CAT I or 150 V DC CAT I
150 V
RMS
CAT II or 150 V DC CAT II
100 V
RMS
CAT III or 100 V DC CAT III
210 V peak, <50% DF, <1 s PW
330 V peak, <20% DF, <1 s PW
300 V
RMS
, Installation Category II; derate at 20 dB/decade above
900 kHz to 13 V peak AC at 3 MHz and above. For non-sinusoidal
waveforms, peak value must be less than 450 V. Excursion above 300
V should be less than 100 ms duration. RMS signal level including
any DC component removed through AC coupling must be limited to
300 V. If these values are exceeded, damage to the instrument may
result. Refer to the Overvoltage Category on the next page.
1
As defined in EN61010-1 on the next page.

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
