Reference
Utility
Push the Utility menu button, and the System Configbottomscreenbuttonto
access submenus.
Thefollowingareexamplesofwhatyoucando
in the U tility menu:
Use Config to select a language or set the time and date.
Use Apps if an installed application module places items in this menu. See the
documentation provided with your application modules for more information.
Use I/O to set up the communication ports.
UseHardCopytosetuphardcopyparameters.(Seepage65,Hard Copy.)
Use Cal to compensate the signal path.
Use Diags to run internal diagnostic routines.
Configure System
Use the System Config menu to access these functions.
Bottom Side Description
System Config
English
French
Italian
German
Spanish
Japanese
Brazilian Portuguese
Simplified Chinese
Traditional Chinese
Korean
Language
Russian
Use to choose your native language. Most on-screen text
appears in the language you choose.
Display Date/Time Use to turn the date/time display On or Off.
Hour Min Use to set the internal clock with the current hour and minute.
Month Day Use to set the internal clock with the current month and day.
Year Use to set the internal clock with the current year.
Set Date & Time
OK Enter Date/Time Sets the date and time of the internal clock.
Power Off Time-Out Use to set the time before an automatic shut down.Battery Time-Outs
Backlight Time-Out Use to set the time before the backlight automatically turns off.
TekSecure Erase
Memory
Erases all nonvolatile waveform and setup memory. For more
information, refer to the TDS3000C Series Digital Phosphor
Oscilloscopes Declassification and Security Instructions.
Version
Usetoseethefirmware version.
TDS3000C Series Oscilloscope User Manual 109
