Model 880 DEPOSITION CONTROLLER
y
SECTION 3.XX
e page 115 of 275 ^
Options/Info, page 5 of 6 Options/Info, page 6 of 6
Displays live frequency measurements from Displays Memory Module information if the
the installed/enabled source sensor cards. optional memory module interface bd. and the
If no crystal/oscillator w/installed/enabled, freq. = zero
memory module are installed and the memory
[only screen w/ live update] module is enabled. See section 3.20 for details.
This information can be useful to the factory if there is a problem. Information also appears after product
power-on during initialization. The initialization process (for diagnostic purposes) is as follows (with
typical LCD screen information):
1. LED displays: non-illuminated.
LCD display: screen: clear
backlight: on
2. LCD display:
Beeper: beeps with the appearance of each line of above text (5 beeps)
3. LCD display: screen clear
LED displays: all segments on (test)
Beeper: 2 Lo/Hi beeps
4. LCD display:
5. LCD display: typical Run Time Screen
LED displays: typical information
check sum validation
Check sums are used to validate the integrity of the user programmable functions for the Model 880. Of the
programs that use check sums, there are three categorical types: one for the film parameters (Main Menu:
Review Film key), another for the process steps (Main Menu: Review Processes key), and finally one for
CST
APP LOADER V01.02(BUILD 5C24)
----------------------------------------------
>APP FOUND:SECTOR E BUILD 3754
>VERIFY APP IN PROGRESS
..............................................
>APP OK
>LAUNCHING APPLICATION...
UIFC: VERSION AUIFA01.01
SYNCING WITH SCUP...60
