p Model 880 DEPOSITION CONTROLLER y
SECTION 4.XX
e page 148 of 275 ^
To: IBM - PC
,
XT
TxD
RxD
CTS
2
3
5
DS R
GND
DTR
6
7
20
To: STC-2002 / model 880
9 PIN FEMALE
RxD
TxD
GND
SHIELD
To: STC-2002 / model 880
9 PIN FEMALE
2
3
9
5
RxD
TxD
GND
2
3
9
5
SHIELD
To: PC HOST
9 PIN FEMALE
RxD
TxD
CTS
DTR
GND
DS R
6
2
3
8
4
5
RS-232 CONNECTIONS
Figure- 4.7: Example Cable to Interface Model 880 To Host PC
Communications Options
Communications Option
The Model 880 supports one communications option board. This is for an industrial network. This
card uses the rear panel option cutout for external connection. This is a factory-installed option.
.recoder (3.10)
I/O interface
hardware (3.5 – 3.7)
outputs/ I/O program (3.8).
I/O programming (section 5)
