Model 880 DEPOSITION CONTROLLER
y
SECTION 5.XX
e page 158 of 275 ^
217 IT Event Final Thickness Trigger (from measurement or external)
218 IT Event Rate measurement system (from crystal onward) failed
219 IT Event Zero Thickness Event Requested / Performed
220 IT Event Setpoint Time Triggered Condition
221 IT Event Setpoint Thickness Triggered Condition
222 IT Event Set Manual Mode Off
223 IT Event Set Manual Mode On
224 IT Event Metronome Timer Event in Seconds (Once Per Second Event)
225 IT Event Metronome Timer Event in Minutes (Once Per Minute Event)
226 IT Event Metronome Timer Event in Hours (Once Per Hour Event)
227 IT Event Begin Job/Process Event
228 IT Event Begin Job/Film Event
229 IT Event Begin Job/Deposit Event
230 IT Event End Of Job/Deposit Event
231 IT Event End Of Job/Film Event
232 IT Event End Of Job/Process Event
233 IT Event Rate Ramp Trigger (Rate Ramp Starts if Enabled)
234 IT Event Gun 1: pocket good
235 IT Event Gun 2: pocket good
236 IT Event Gun 3: pocket good
237 IT Event Gun 4: pocket good
238 IT Event Gun 5: pocket good
239 IT Event Gun 6: pocket good
240 IT Event Gun 7: pocket good
241 IT Event Gun 8: pocket good
242 IT Event Release Film Hold Event
243 IT Event Release Soak Hold Event
244 IT Event Trigger Request To Rescan Sensor Map Matrix
245 IT Event Channel 1: Thickness Zero
246 IT Event Channel 2: Thickness Zero
247 IT Event Channel 3: Thickness Zero
248 IT Event Channel 4: Thickness Zero
249 IT Event Channel 5: Thickness Zero
250 IT Event Channel 6: Thickness Zero
251 IT Event Channel 7: Thickness Zero
252 IT Event Channel 8: Thickness Zero
253 IT Event Gun 1: Reset Output Power (only works on non-active sources)
254 IT Event Gun 2: Reset Output Power (only works on non-active sources)
255 IT Event Gun 3: Reset Output Power (only works on non-active sources)
256 IT Event Gun 4: Reset Output Power (only works on non-active sources)
257 IT Event Gun 5: Reset Output Power (only works on non-active sources)
258 IT Event Gun 6: Reset Output Power (only works on non-active sources)
259 IT Event Gun 7: Reset Output Power (only works on non-active sources)
260 IT Event Gun 8: Reset Output Power (only works on non-active sources)
261 IT Event Channel 1: User Fource Fails Sensor Channel
262 IT Event Channel 2: User Fource Fails Sensor Channel
263 IT Event Channel 3: User Fource Fails Sensor Channel
264 IT Event Channel 4: User Fource Fails Sensor Channel
265 IT Event Channel 5: User Fource Fails Sensor Channel
266 IT Event Channel 6: User Fource Fails Sensor Channel
267 IT Event Channel 7: User Fource Fails Sensor Channel
268 IT Event Channel 8: User Fource Fails Sensor Channel
269 IT Event Measurement at Rate for 4 Seconds
(event 154 function duplicate)
270 IT Event I/O Auxiliary Stop 1
271 IT Event I/O Auxiliary Stop 2
272 IT Event I/O Auxiliary Stop 3
273 IT Event I/O Auxiliary Stop 4
274 IT Event Start Coupling (for non-sequencing film starts linkage)
275-299 Available
300 - 399 All State 1
st
Soft Node To Last Soft Node
400 To 409 ISCAD Counter Modulo 100 Counters [10 counters]
Table 5.4: Event And State ID List. […continued from previous 3 pages]
Function Index
I INPUT
O OUTPUT
T TRIP
A ARM
D DROP
S SET
C CLEAR
Type Values
B Boolean
V Scalar
M Bitmap
(combined bit
weights)
E Event
