Model 880 DEPOSITION CONTROLLER
y
SECTION 3.XX
e page 128 of 275 ^
Note
Note If the text 'TEST' does not appear in the box to the left of the crystal information at this
point, the unit is not in the TEST mode. Enter the TEST mode as described in the second paragraph of
Section 2.7.)
The STC-2002 will then enter the RISE 1 phase for film 1. Notice the RUN (TIME) number on the
display counting up while the PHASE (TIME) counts down. When the PHASE (TIME) reaches 0:00, the
next phase is entered. At this point, you will see SOAK 1 appear on the display. The power level will
remain at 15.0% for the 10 seconds that the STC-2002 is in the SOAK phase for film 1.
When the DEPOSIT phase is entered, the THICK number on the display is zeroed and will start
accumulating. The PHASE (TIME) now starts counting up. The RATE number is near 20 Å/s and the
