Model 880 DEPOSITION CONTROLLER
y
SECTION 5.XX
e page 156 of 275 ^
85 I - M Istate Xtal Failed Map- Failed Sensors
86 I - V Istate Sample / Hold Status- No cycle Activity, State Not Important [0]
86 I - V Istate Sample / Hold Status- Sampling, Xtal is Read for Control [1]
86 I - V Istate Sample / Hold Status- Holding, Xtal Covered, estimated Rate [2]
87 I - M Istate Crystal Life Over Bounds
88 I - M Istate Max. Power Condition- SRC @ Max Power = True, Else False
88 I - M Istate Max. Power Condition- No Sources @ Max Power Limit [0]
88 I - M Istate Max. Power Condition- Source #1 @ Max Power Limit [1]
88 I - M Istate Max. Power Condition- Source #2 @ Max Power Limit [2]
88 I - M Istate Max. Power Condition- Source #3 @ Max Power Limit [4]
88 I - M Istate Max. Power Condition- Source #4 @ Max Power Limit [8]
88 I - M Istate Max. Power Condition- Source #5 @ Max Power Limit [16]
88 I - M Istate Max. Power Condition- Source #6 @ Max Power Limit [32]
88 I - M Istate Max. Power Condition- Source #7 @ Max Power Limit [64]
88 I - M Istate Max. Power Condition- Source #8 @ Max Power Limit [128]
88 I - M Istate Max. Power Condition- All Sources @ Max Power Limit [255]
89 I - B Istate Increment Key - Hand Controller
90 I - B Istate Decrement Key - Hand Controller
91 I - B Istate Stop Key – Hand Controller
92 I - V Istate Process Verify Phase [0]
(sequencing mode
only)
92 I - V Istate Process Stopped, Number Displayed [1]
(sequencing mode
only)
92 I - V Istate Process Resting [2]
(sequencing mode
only)
92 I - V Istate Process Busy [3]
(sequencing mode
only)
92 I - V Istate Process Waiting [4]
(sequencing mode
only)
92 I - V Istate Process Error [5]
(sequencing mode
only)
93 I - V Istate Process Not Failed [0]
93 I - V Istate Bad Recipe [1]
93 I - V Istate Process Aborted [2]
94 I - B Istate True if front panel is communicating
95 I - B Istate true when Sensor card failure occurs
96 I - B Istate T=front panel PCB (UIFC) not communicating (w/o STOP key)
97 I - B Istate True = Crystal Test / Simulate Mode Activated
98 I - M Istate Rotator Sync Map- Synchronization needed, 1 per each Source
99 I - V Istate Active Source Being Controlled [1 To 8]
100 I - B Istate True = Non-Sequencing Mode Active
101 I - V Istate Active Map of Source Sensor usage
102 I - M Istate Available Modules (in bit map pairs)
103 I - V Istate Source 1: Pocket Code [0-63] (in Film Program)
104 I - V Istate Source 2: Pocket Code [0-63] (in Film Program)
105 I - V Istate Source 3: Pocket Code [0-63] (in Film Program)
106 I - V Istate Source 4: Pocket Code [0-63] (in Film Program)
107 I - V Istate Source 5: Pocket Code [0-63] (in Film Program)
108 I - V Istate Source 6: Pocket Code [0-63] (in Film Program)
109 I - V Istate Source 7: Pocket Code [0-63] (in Film Program)
110 I - V Istate Source 8: Pocket Code [0-63] (in Film Program)
111 I - V Istate I/O Slot 1: PCB Status: Not Established Yet [0]
111 I - V Istate I/O Slot 1: PCB Status: Not Detected, Config = Empty [1]
111 I - V Istate I/O Slot 1: PCB Status: Disabled Input Card in Slot [2]
111 I - V Istate I/O Slot 1: PCB Status: Disabled Output Card in Slot [3]
111 I - V Istate I/O Slot 1: PCB Status: Input Card Detected in Slot [4]
111 I - V Istate I/O Slot 1: PCB Status: Output Card Detected in Slot [5]
111 I - V Istate I/O Slot 1: PCB Status: MIA, Config'd Input on Empty Slot [6]1
111 I - V Istate I/O Slot 1: PCB Status: Conflict, have output, need input card [7]
111 I - V Istate I/O Slot 1: PCB Status: MIA, Config'd Output on Empty Slot [8]
111 I - V Istate I/O Slot 1: PCB Status: Conflict, have input, need output card [9]
112 I - V Istate I/O Slot 2: PCB Status (see Slot 1 breakout)
113 I - V Istate I/O Slot 3: PCB Status (see Slot 1 breakout)
114 I - V Istate I/O Slot 4: PCB Status (see Slot 1 breakout)
115 I - V Istate Sensor Slot A Status: Unknown (until PCB is polled) [0]
115 I - V Istate Sensor Slot A Status: PCB Located by Communication [1]
115 I - V Istate Sensor Slot A Status: PCB Not Located by Communication [2]
115 I - V Istate Sensor Slot A Status: PCB exists but incorrect Configuration [3]
115 I - V Istate Sensor Slot A Status: No PCB but correct Configuration [4]
115 I - V Istate Sensor Slot A Status: PCB has Incompatible Software Rev [5]
ID number | Valid Functions – Type | Class | Description
