Model 880 DEPOSITION CONTROLLER
y
SECTION 5.XX
e page 184 of 275 ^
(O64). This rung serves no useful purpose other than to demonstrate the use of one of the four
soft-switch inputs and one of the uncommitted LED indicators. When the unit is running, pressing
the leftmost membrane key will light the LED for the duration of the depression. A slight lag
between activation and deactivation of switch and the tracking of the LED illumination is normal.
Pressing and releasing the front panel switch quickly enough will result in no LED lighting,
demonstrating the need to have inputs persist long enough to be sampled and recognized.
