Model 880 DEPOSITION CONTROLLER
y
SECTION 6.XX
e page 197 of 276 ^
@16 = UIFC sys_trap codes. In nnnn,nnnn form.
Read at power up, can be refreshed for recent reading from UIFC via ^U?
command. Reset from SCUP via ^U! command. Note, the ^U? command
requests a new sys_trap code from UIFC, but requires a separate @16 to
interrogate the reading if changed. Once a sys_trap code is non-zero, it will not
change or be overwritten until cleared from the UIFC front panel or via the YH
command passthru or the ^U! command.
@17..@29 reserved for future UIFC codes.
@30 = ReadBack SCUP Memory Module status. Returns CRDSTAT_class integer.
0 CRDSTAT_uninst Uninstalled option.
1 CRDSTAT_error Unavailable or unpresent when spoken to.
2 CRDSTAT_unfmtRO Present but format not recognized.
3 CRDSTAT_unfmt Present but format not recognized.
4 CRDSTAT_wrprot Present but write-protected.
5 CRDSTAT_readwrite Totally available.
@31 = Readback MemModule ProdID & Serial# returns integer, integer where first
integer is 9/10/11 for FRAM memory module w/1/2/3 chips. If chip's status is
not above unformatted, then returns 0,0. Serial number in range of 1..1000 is one
which was formatted automatically on SCUP system. Factory registered ones
start at serial # 2001 and up. This leaves an additional area from 1001..2000 for
future special purpose.
@32 = Readback Data Compatibility code returns number,number where 1st number
is product code (such as COBRASCUP #4) and second number is a dialect/data
representation covenant code which determines whether the data saved to file is
expected to be interpreted for read/write of params/accounting/sequences/ and
RLLE steps. If chip's status is not above unfmt, then returns 0,0 . This
information pertains to the portable data on the CARD.
@33 = Readback Data Compatibility code returns number,number where 1st number
is product code (such as COBRASCUP #4) and second number is a dialect/data
representation covenant code which determines whether the data saved to file is
expected to be interpreted. This information pertains to the SCUP firmware's
desired/expected information profile. It must MATCH EXACTLY the card in
order to load/clone.
______________________________________________________________________
Initialization Commands Example
Command @
Response ASTC200/B15
Description The version request message. Where the 'A' might be a 'B' if the instrument was reset
since the last power loss acknowledgment message.
______________________________________________________________________
Reset Power Lost Status
This is used to reset the power lost status of the Model 880. See Section x3 for a complete description.
Command: ?
Mnemonic: EXCT_ackpl (acknowledge power loss)
Parameters: None
Description: Acknowledge Power Loss status.
Returns: [RZCD_AOK] (an A or B)
______________________________________________________________________
Initialization Commands Example
Command ?
Response A
Description The reset power loss status message. Always an A since the message resets the 'B' status
