Tenda AP4 User Manual

120
Name
Description
Ping Interval
It specifies the interval at which the device transmits packets to ping the target IP
address.
Ping Startup Delay
It specifies the delay time for the device to enable the Ping Watch Dog function after
the device completes startup.
Threshold of Lost
Packets
It specifies the threshold of lost packet that triggers reboot. Range: 1 to 65535,
default: 3.
For example, if 5 is set, the device will reboot automatically when it sends 5 Ping
packets to target IP address/domain name, but does not receive response.
7.6.6 DMZ host
This function is available only when the device works in WISP or Router mode.
A DMZ host on a LAN can communicate with the internet without limit. You can set a computer that
require higher internet connection throughput, such as a computer used for video conferencing or
online gaming, as a DMZ host for better user experience.
 A computer set to DMZ host is not protected by the firewall of the device.
 A hacker may leverage the DMZ host to attack your LAN. Therefore, enable the DMZ function only
when necessary.
Configuring DMZ host
Step 1 Log into the web UI of the device, and choose Advanced > Network Service.
Step 2 Enable the DMZ Host function.
Step 3 Enter the IP address of the device to be set to DMZ host.
Step 4 Click Save on the bottom of this page.
----End

Tenda AP4 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.483 GHz
Number of users	5 user(s)
Operating modes	Access Point (AP), Repeater, WISP
Transmitting power	20 dBmW
Maximum indoor range	40 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Output current	0.6 A
Output voltage	9 V
Power consumption (typical)	4 W
Placement	Table, Wall
Certification	FCC, CE, VoC, Rohs
Product color	Black
LED indicators	LAN, System, WLAN, WPS
Antenna gain level (max)	5 dBi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Supported network protocols	http/https
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	31.5 mm
Width	148 mm
Height	146.2 mm
