Tenda AX3000 User Manual

26
Example of setting up a wireless network encrypted with WPA or WPA2

Networking requirement
A highly secure wireless network is required and a RADIUS server is available. In this case, WPA or
WPA2 mode is recommended.
Assume that the IP address of the RADIUS server is 192.168.0.200, the RADIUS password is
12345678, the port number for authentication is 1812, and the SSID is hot_spot. See the following
figure.

Configuration procedure
Configure the AP.
Assume that the first SSID of the 2.4 GHz radio band of the AP is to be configured.
Step 1 Choose Wireless > SSID.
Step 2 Select the first SSID from the SSID drop-down list menu
Step 3 Set Status to Enable.
Step 4 Change the value of the SSID text box to hot_spot.
Step 5 Set Security Mode to WPA2.
Internet
Router
PoE switch
AP
IP: 192.168.0.254
SSID: hot_spot
RADIUS server
IP: 192.168.0.200
LAN port
WAN port

Tenda AX3000 Specifications

General

Wi-Fi Standard	Wi-Fi 6 (802.11ax)
MU-MIMO	Yes
Beamforming	Yes
OFDMA	Yes
Frequency Bands	2.4 GHz, 5 GHz
Ports	1 x 10/100/1000 Mbps WAN port, 3 x 10/100/1000 Mbps LAN ports
Antenna	4 x external antennas
Security	WPA3, WPA2, WPA, WEP
Button	WPS/Reset
