4
2 Web UI operations
2.1 Layout
The web UI of the AP consists of four sections, including the level-1, and level-2 navigation bars, tab
page area, and the configuration area. See the following figure.
Functions or parameters displayed in gray on the web UI are not supported yet or cannot be modified
under the current configurations.
No. Name Description
1 Level-1 navigation bar
Used to display the function menu of the AP. Users can select
functions in the navigation bars and the configuration appears in the
configuration area.
2 Level-2 navigation bar
3 Tab page area
4 Configuration area Used to modify or view your configuration.
