6.1.2 Example of SSID configurations
Example of setting up an open wireless network
Networking requirement
In a hotel lounge, guests can connect to the wireless network without a password and access the
internet through the WiFi network.
Configuration procedure
Assume that the first SSID of the 2.4 GHz radio band of the AP is to be configured.
Step 1 Choose Wireless > SSID.
Step 2 Select the first SSID from the SSID drop-down list menu.
Step 3 Set Status to Enable.
Step 4 Change the value of the SSID text box to FREE.
Step 5 Set Security Mode to None.
Step 6 Click Save.
Internet
Router
PoE switch
AP
WiFi: FREE
LAN
WAN

Tenda i27 Specifications

General

Antenna type	External
Antennas quantity	2
Antenna gain level (max)	4 dBi
2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3at
Virtual LAN features	Tagged VLAN
Spread spectrum method	OFDMA
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2976 Mbit/s
Maximum data transfer rate (5 GHz)	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Power consumption (max)	14.04 W
Placement	Ceiling, Wall
Product color	White
Security algorithms	SSID, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	Hidden SSID
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	38 mm
Width	178 mm
