Tenda i27 User Manual

Document version: V1.0
15
4.3 Traffic statistics
The Traffic Statistics page allows you to check statistical information about traffic based on SSIDs.
To access the page, choose Status > Traffic Statistics.
Parameter description
Parameter
Description
SSID
It specifies the wireless network name.
Received Traffic
It specifies the total number of bytes received by a wireless network.
Received Packets (Qty.)
It specifies the total number of packets received by a wireless network.
Transmitted Traffic
It specifies the total number of bytes transmitted by a wireless network.
Transmitted Packets (Qty.)
It specifies the total number of packets transmitted by a wireless network.
All the statistics are cleared when the wireless function is disabled or this device is rebooted. All the
wireless network statistics of an SSID are cleared when the SSID is disabled.

Tenda i27 Specifications

General

Antenna type	External
Antennas quantity	2
Antenna gain level (max)	4 dBi
2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3at
Virtual LAN features	Tagged VLAN
Spread spectrum method	OFDMA
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2976 Mbit/s
Maximum data transfer rate (5 GHz)	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Power consumption (max)	14.04 W
Placement	Ceiling, Wall
Product color	White
Security algorithms	SSID, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	Hidden SSID
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	38 mm
Width	178 mm
