Tenda i27 User Manual

Document version: V1.0
90
8.6 Uplink check
8.6.1 Overview
In AP mode, the AP connects to its upstream network using the Ethernet port (LAN port). If a critical
node between the LAN port and the upstream network fails, the AP as well as the wireless devices
connected to the AP cannot access the upstream network. If uplink detection is enabled, the AP
regularly pings specified hosts through the LAN port. If all the hosts are not reachable, the AP stops
its wireless service and wireless clients cannot find the SSIDs of the AP. The client can reconnect to
the AP only after the connection between the AP and the upstream networks is recovered.
If the uplink of the AP with uplink detection enabled is faulty, wireless clients can connect to the
upstream network through another nearby AP that works properly.
See the following topology (The LAN port serves as the uplink port).
Ethernet port
Internet
Router
PoE switch
AP
WAN
LAN
Devices
Uplink network

Tenda i27 Specifications

General

Antenna type	External
Antennas quantity	2
Antenna gain level (max)	4 dBi
2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3at
Virtual LAN features	Tagged VLAN
Spread spectrum method	OFDMA
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2976 Mbit/s
Maximum data transfer rate (5 GHz)	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Power consumption (max)	14.04 W
Placement	Ceiling, Wall
Product color	White
Security algorithms	SSID, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	Hidden SSID
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	38 mm
Width	178 mm
