Tenda i27 User Manual

Document version: V1.0
14
4.2 Wireless status
The Wireless Status page allows you to check RF Status and SSID Status of the AP.
To access the page, choose Status > Wireless Status.
Parameter description
Parameter
Description
RF Status
RF
It specifies whether the wireless function of the AP is enabled.
Network Mode
It specifies the network mode currently enabled by the AP on each
radio band.
Channel
It specifies the current working channel of the AP.
SSID Status
SSID
It specifies the names of all the wireless networks of the AP.
MAC Address
It specifies the physical address of the corresponding wireless
network.
Status
It specifies whether or not the corresponding WiFi network is
enabled.
Security Mode
It specifies the security modes of the wireless networks
corresponding to the SSIDs of the AP.

Tenda i27 Specifications

General

Antenna type	External
Antennas quantity	2
Antenna gain level (max)	4 dBi
2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3at
Virtual LAN features	Tagged VLAN
Spread spectrum method	OFDMA
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2976 Mbit/s
Maximum data transfer rate (5 GHz)	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Power consumption (max)	14.04 W
Placement	Ceiling, Wall
Product color	White
Security algorithms	SSID, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	Hidden SSID
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	38 mm
Width	178 mm
