Tenda i27 User Manual

Document version: V1.0
4
2 Web UI
2.1 Layout
The web UI of the AP consists of four sections, including the level-1, and level-2 navigation bars, tab
page area, and the configuration area. See the following figure.
Functions or parameters displayed in gray on the web UI are not supported yet or cannot be modified
under the current configurations.
No.
Name
Description
1
Level-1 navigation bar
Used to display the function menu of the AP. Users can select
functions in the navigation bars and the configuration appears in the
configuration area.
2
Level-2 navigation bar
3
Tab page area
4
Configuration area
Used to modify or view your configuration.
2
1
3
4

Tenda i27 Specifications

General

Antenna type	External
Antennas quantity	2
Antenna gain level (max)	4 dBi
2.4 GHz	Yes
MIMO type	Multi User MIMO
Number of users	254 user(s)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.3at
Virtual LAN features	Tagged VLAN
Spread spectrum method	OFDMA
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	2976 Mbit/s
Maximum data transfer rate (5 GHz)	2402 Mbit/s
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Power consumption (max)	14.04 W
Placement	Ceiling, Wall
Product color	White
Security algorithms	SSID, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	Hidden SSID
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	38 mm
Width	178 mm
