CONTROLS AND INSTRUMENTS
1. FUEL GAUGE
2. SWING LOCKED INDICATOR
3. ENGINE COOLANT TEMPERATURE GAUGE
4. REAR AXLE CENTERED INDICATOR
5. ENGINE OIL PRESSURE GAUGE
6. LEFT TURN SIGNAL INDICATOR
7. VOLTMETER
8. LOW OIL PRESSURE INDICATOR
9. DASH LIGHT SWITCH
10. WORK LIGHT SWITCH
11. SWING BRAKE RELEASE
12. DEFROSTER FAN SWITCH
13. OUTRIGGER EXTEND/RETRACT MASTER
14. SWING LOCK SWITCH
15. STEERING SWITCH
16. REAR STEER SWITCH
17. TACHOMETER
18. WAIT TO START LIGHT
19. TRANSMISSION TEMPERATURE
20. RIGHT TURN SIGNAL INDICATOR
21. TRANSMISSION OIL PRESSURE
22. LOW AIR WARNING LIGHT
23. BUBBLE LEVEL
24. AIR PRESSURE GAUGE
25. PARK BRAKE INDICATOR
26. LOW WATER INDICATOR
27. ENGINE WARNING INDICATOR
28. ENGINE DIAGNOSTIC INDICATOR
29. ENGINE STOP / FAULT INDICATOR
30. IGNITION SWITCH
31. LEFT FRONT OUTRIGGER SWITCH
32. LEFT REAR OUTRIGGER SWITCH
33. RIGHT FRONT OUTRIGGER SWITCH
34. RIGHT REAR OUTRIGGER SWITCH
35. EMERGENCY STOP
36. PARKING BRAKE SWITCH
37. AXLE DISENGAGE / RANGE SHIFT
38. HAND THROTTLE
39. SWING BEARING GREASE FITTING
40. SWING GEAR GREASE FITTING
41. SWING BRAKE
42. BOOM EXTEND RETRACT PEDAL
43. ACCELERATOR
44. BRAKE PEDAL
45. WIPER CONTROL
46. GEAR SELECTOR
47. SWING / AUX WINCH CONTROL / HORN
(See Page 2-11)
48. BOOM HOIST / MAIN WINCH CONTROL / HORN
(See Page 2-11)
49. CAB FAN SPEED
50. CAB HEAT/AC SELECTOR
51. CAB HEATER TEMPERATURE
52. FIRE EXTINGUISHER
(See Page 2-12)
UPPER CONTROLS & INSTRUMENTS KEY
RT700 Revised: April 2005Page 2 - 5
