Issued: July 2003
This manual contains instructions and information on the
operation, maintenance, lubrication and adjustments of the
Rough Terrain Crane. The operator should not attempt to
operate the machine before he has gained a thorough
1. UPPERSTRUCTURE
2. BOOM ATTACHMENT
3. CARRIER
4. OUTRIGGERS
RIGHT HAND/LEFT HAND
understanding of the material presented in the following
pages.
To aid in understanding the contents of this manual, the fol-
lowing terms will always have themeanings given whenever
they are used.
The upperstructure weldment, swing mechanism, counter-
weight, cab.
The telescopic crane boom with hydraulic winch, lift cylin-
der, hook block assembly, jib arrangement.
The chassis complete, power unit, swing bearing, transmis-
sion, planetary axles, outrigger assemblies.
The beams, cylinders, floats, boxes, hydraulic control sys-
tem.
All references to right or left hand will correspond to the op-
erator’s right or left hand when he is facing forward from the
operator’s seat, with the rear mounted engine to his back.
NOMENCLATURE
4
4
1
2
3
RT775
