Terex TC29 User Manual

Inspection plan
To be carried out by trained dealer personnel.
O = Checking, maintenance
X = Replacement
Operating hours
min
2x
min
1x
Perform work with machine at operating
temperature
after
100
every
500
every
1,000
yea-
rly
yea-
rly
1 Check whether machine-specific instruction book
is in the machine
O O
2 Change engine oil X X X
3 Change engine oil filter X X X
4 Drain water from fuel tank O O O
5 Change fuel filter X X X
6 Check air intake O O
7 Change air filter - main cartridge in compliance with service
indicator
X
8 Change air filter - safety cartridge as required
1)
9 Clean cooling fins of hydraulic oil cooler O O O
The cleaning intervals should be shortened
if there is high exposure to dust
10 Clean cooling fins of water cooler O O O
The cleaning intervals should be shortened
if there is high exposure to dust
11 Check antifreeze level in coolant O
12 Change coolant as required
1)
13 Check V-belt tension O O
14 Check engine mounts and pump attachments O O
15 Check engine speed adjustment, top-end and
low-idle idle speed
O O
16 Check valve lash of engine and adjust if
necessary
O O O
17 Check injection nozzles O
18 Check injection pump O
19 Check acid level and battery connections O O
20 Check condition of crawler chains O O
21 Check secure fastening of sprocket, crawler gear
units and hydraulic motor
O O
22 Check smooth running of bottom and top rollers O O
23 Check bearing bushings and bolts of work
equipment and re-adjust "free of clearance"
O O
O = Checking, maintenance
X = Replacement
Operating hours
min
2x
min
1x
Perform work with machine at operating
temperature
after
100
every
500
every
1,000
yea-
rly
yea-
rly
24 Check electrical indicating and warning
elements, and lighting system
O O
25 Check smooth running of operator controls and
adjust if necessary
O O
26 Check tightness of all pipes, hoses, control
valve, hydraulic pumps, cylinders, etc.
O O
When tightening hose and pipe
connections, screw-in couplings must be locked
to prevent rotation.
27 Check or change hydraulic oil O O X
2)
X
28 Replace hydraulic oil return filter insert X X X
29 Replace breather X X
30 Crawler gear units: Check or replace oil X O X X
31 Check that swing gear unit is securely fastened O O O
32 Check that ring gear attachment screws are
securely fastened
O O O
33 Grease machine in compliance with overview of
lubricating points
O O
34 Check function, condition and completeness of
safety equipment
O O
35 Function of brake valves O O
36 Hydraulic function check with pressure function
test
O O
37 Test run and test work O O
38 Initial inspection card and return to manufacturer O O
3)
1. at least every 2 years
2. Extension of oil change interval in compliance with oil sample analysis and lab report.
For further information see Chapter 7.3
3. within warranty
