7 Maintenance and care
96 TW85
7.9.13.3 Front axle transmission
Checking oil level
• Remove the filling and inspection plug (83/1)
check and top up oil if required.
Changing oil
• Park the machine on level ground.
• Open the inspection plug (83/1) on the
transmission.
• Open the drain plug (83/2) on the transmission
and drain oil.
• Flush the transmission if necessary.
• Screw back on the drain plug carefully.
• Pour in oil using the filling and inspection hole
(83/1) until oil escapes.
• Carefully close the filling and inspection plug.
HM32-083-N
1
2
1
HML32, HML32AL
HML32S
2
1
Fig. 83 Transmission
