Read Operators Manual For SafetyPARTS MANUAL
Copyright © 2007 Terramite Corporation
T7 Backhoe Assembly 180
ITEM PART NUMBER DESCRIPTION QTY.
1 11150 Swing, 180, T7/T9 1
2 17055 Bushing, 1.5"ID x 1.75"OD x 2"L 4
3 17244 Pin, 5
1
/2”, Swing Cylinder 2
4 11155 Plate, Swing Cylinder, 180, T7/T9 1
5 17252 Bushing, 1.5"ID x 1.75"OD x 1.25"L, T7/T9 6
6 17253 Pin, 4
3
/4”, Swing Pivot, 180, T7/T9 2
7 81169 Cylinder, Trunnion Swing, 180, T7/T9 2
8 21420 Pin, Cotter, Case Hard 2
9 10292 Assembly, Boom, T7 (Includes Decals) 1
10 10237 Boom Latch, Curved Boom, T5D/T6/T7/T9 1
11 10271 Assembly, Dipper, T7 (Includes Decals) 1
12 81190 Cylinder, Crowd, T7 1
13 10700 Pin, 6
7
/8” Crowd & Rear Curl Cylinder, T5C/T6/T7/T9 3
14 10406 Pin, 7
1
/4” Boom to Dipper, T5B/T5D/T6/T7/T9 2
15 20082 Nut,
3
/8" NC Flange Z 6
16 22123 Bolt,
3
/8-16 x 1
1
/4" Gr8 Z 6
17 17208 Pin, 8
1
/4” Boom Cylinder to Swing, T6/T7/T9 1
18 22200 Ring, External, Snap, 1
1
/2", 180, T7/T9 4
19 22197 Bolt,
3
/4-16 x 2
3
/4" Gr8 Z 4
20 22199 Nut,
3
/4-16, Nylon Lock Gr8 Z 4
21 15138 Bracket, Engine Mounting, Front, Perkins, 20hp. 1
22 15136 Bracket, Engine Mounting, Rear, Perkins, 20hp. 2
23 48024 Mount, Rubber Isolator 4
24 22021 Bolt,
1
/2-13 x 3" NC Gr8 Z 4
25 22081 Washer,
1
/2" USS 4
26 22080 Washer,
1
/2" x 2" OD Z 4
27 28500 Nut,
1
/2" NC Lock Z 4
28 24007 Spacer, Frame, Front Valve Washer 4
29 10062 Bracket, Radiator Arm (Left) Perkins 1
30 10063 Bracket, Radiator Arm (Right) Perkins 1
31 22008 Bolt,
3
/8-16 x 1" Gr 8 ZP, T5C/T5D/T6/T7/T9/Sweeper 4
32 20134 Fitting, #6 O-ring Plug 2
33 16279 Cover, Rear Valve, V-10, 180, T7/T9 1
34 15147 Plate, Back Valve Cover, V-10 6 Spool 1
35 15148 Plate, Top Valve Cover, V-10 6 Spool 1
36 22025 Bolt,
1
/4" x
3
/4" NC Gr8, T5C/T5D/T6/T7/T9/Sweeper 3
37 24008 Washer,
1
/4" Flat USS 13
38 22045 Bolt,
5
/16" x
3
/4" NC Gr8 Z 7
39 28504 Nut,
1
/4" NC Lock Z 3
40 22212 Bolt,
5
/16" NC x 4
1
/2" L, Gr8 Z 3
41 17257 Spacer, Boom Hose 3
42 17258 Spacer, Swing Hose Guide 1
43 22213 Bolt,
5
/16" NC x 7" L, Gr 8 Z 1
44 28020 Washer,
5
/16", Lock Z 4
45 23003 Nut,
5
/16-18, Hex NC 4
46 17256 Stop, Plastic Swing 2
47 81222 Cylinder, Boom, T7 1
o
o
o
o
o
o
o
2.53
