TEXA ACKF01 - Page 89

ACKF01_GB_00 TEXA S.p.A. 89/122
Example 7
(1) Konfort unit’s red service hose
(2) ¼’’ x R134a adapter P/N 3900173
(3) “Spring-lock adaptor P/N 42070086
Example 9
Illustration of the full set of flushing adapters
included in the kit:
(1) Universal flushing adapter set P/N 3134
(2) Adaptor ¼’’ x 3/8’’ P/N 3900172
(3) Adaptor ¼’’ x HP R134a P/N 3900173
(4) Adaptor 3/8’’ x HP R134a P/N 3900174
Example 8
If using the VW-AUDI specific flushing
adapter set :
(1) Konfort’s red service hose
(2) 3/8’’ x HP R134A adapter P/N 3900174
(3) Audi-Volkswagen specific adaptor.
(Audi-Volkswagen adapter set is not
included with the flushing kit. It needs to be
purchased from VW Group directly)
1
2 3 4
3
3
2
2
1
1
