TEXA ACKF01 - Konfort Unit Preparation

ACKF01_GB_00 TEXA S.p.A. 83/122
6.2 Konfort unit preparation for flushing
The following steps are required to set the unit for flushing.
.
Connect :
(1) Red flushing hose P/N 3900171
(2) Inlet of flushing canister P/N 74350486
Connect :
(1) Konfort unit’s blue service hose
(2) Outlet of flushing canister P/N 74350486
Connect :
(1) Red flushing hose P/N 3900171
(2) ¼’’ x 3/8’’ adapter P/N 3900172
1
2
1
2
2
1
