6.5 Flushing systems with expansion valve
6.5.1 Flushing the evaporator side
In order to prevent particles from the faulty compressor contaminating the rest of the system;
start flushing towards the compressor location in the regular flow of the A/C system .
Connect the Konfort unit to system as following :
(1) Konfort red service hose with HP coupler to the receiver drier location
(2) Canister red service hose 3/8’’ SAE P/N 3900171 to the compressor location
(1)
(2)
Compressor
location
Receiver
drier
location
Evaporator
Condenser
