ACKF01_GB_00 TEXA S.p.A. 97/122
6.6.4 Back-flushing the accumulator-compressor junction
In order to perform the final pass of flushing, reverse the connections to the system. In this
situation you will be back-flushing towards the accumulator location and against the regular
flow of the A/C system.
Connect the Konfort unit to system as following:
(1)Konfort red service hose with HP coupler to the compressor location
(2)Canister red service hose 3/8’’ SAE P/N 3900171 to the accumulator location
Compressor
location
Accumulator
location
(1)
(2)
Condenser
Evaporator
Orifice tube
location
