TAPE AND REEL INFORMATION

*All dimensions are nominal

Device Package

Type

Package

Drawing

Pins SPQ Reel

Diameter

(mm)

Reel

Width

W1 (mm)

(mm)

Pin1

Quadrant

CC1101RTKR VQFN RTK 20 3000 330.0 12.4 4.3 4.3 1.5 8.0 12.0 Q2

PACKAGE MATERIALS INFORMATION

www.ti.com 10-Oct-2012

Pack Materials-Page 1
